ISUZU 16000 liter tank fire tanker fighting vehicle

Fire truck, also known as fire engines, refer to special vehicles used to perform fire fighting tasks. The fire department in most countries of the world will also use it for other emergency rescue purposes.


  • Brand:

    heritagetrucksolution.COM
  • Model No.:

    CL5234GXFQ2
  • Minimum Order Quantity:

    1 Unit
  • Price:

    USD92000
  • Payment Terms:

    T/T, L/C, Western Union
  • Delivery Time:

    25~35 days after we get the deposit
  • Shipping:

    Ro-Ro/Bulk cargo/Container shipment / SKD / CKD / etc
  • Overview
  • Parameters

ISUZU 16000 liter tank fire tanker fighting vehicle


A firefighting apparatus is vehicle that has been customized for use during firefighting operations.Our vehicles are highly customized depending on their needs and the duty they will be performing. These duties can include firefighting, vehicle extrication, dangerous goods investigations, urban search and rescue, medical emergency, swift water rescue and plane crashes.


Quick Details


Product name

Fire fighting truck

Water Tank Capacity

11000L

Foam Tank Capacity

5000L

Chassis Brand

ISUZU

Horsepower

300hp

Fire Pump

CB10/60

Fire Monitor

PS48


Applications


Fire truck is mainly used for fire response tasks, most national fire departments, also use it for other emergency rescue purposes.Fire engines can transport firefighters to disaster sites and provide them with a variety of tools to carry out relief missions.



Competitive Advantages

1.ISUZU chassis and engine , perfect and reliable performance.

2.Equipped with multiple fire hose coupling and all kinds of fire fighting equipment in tool cabinet.

3.Independent fire pump room , ensure  the smooth progress of the work.

4.Intelligent control integration system ,mange the working state of appearance directly

5.It is with ISUZU chassis ,perfect performance!



Product Details





Customer Services





Product Parameters


Chassis Specification

Truck model

CLW5234GXFQ2

Cab

ISUZU FVZ CABIN

Driving Type

6*4 Left hand driving

Max Speed (km/h)

85

Overall dimension(mm)


9525*2480*3500


GVW( kg)

23000

Mass in working order( kg)

12250

Wheelbase(mm)

4650+1350

F/R track base(mm)

1960/1855

F/R overhang(mm)

1335/2300

Approach/Departure Angel

26/14

Tire

11.00R20

Clutch

Single-plate dry diaphragm spring clutch

Steering

Hydraulic steering with power assistance

Gear box

FAST 9-speed

Bridge

Front axle

7T

Rear axle

18T

Engine

Model

6KH1-TC

Fuel Type

Diesel fuel

Type

Water-cooled four-stroke,, direct injection, turbocharged

Exhaust(ml)

7790

Max output power(hp)

300

Upper-Body  specification


Tank

Structure

Welding, there is clapboard inner.

Material

Water Tank

High quality carbon steel plate, anti-rust treatment

Capacity



Total

16000L


Water Tank 11000L

Foam Tank

5000L

Equipment box

Equipment box: at the back of carriage, there are two-layer clapboard, can store equipment. There is safe ladder to up and down on the back of equipment box.
Structure: whole frame is welded to ensure intension and rigidity.
Material: frame is high quality steel, inner plague is aluminum embossed sheet, surface is anodic processed.

pump room

on the rear or central of truck, there are pump system and pipeline, reasonable structure. Easily operate all meters and operate-switch.

Special

PartsParameter

Fire Pump

Type

Normal pressure fire pump

Model

CB10/60

Flux

60L/S

Pressure

1.0Mpa

Fire Monitor

Type

For waterand foam

Model

PL48

Flux

38L/S

Pressure

1.0Mpa

Additional drive  system

Use sandwich PTO, splashing-type lubricate, can put out fire when driving.

Additional operation system

PTP operation lever, fire pump valve operation lever, electronic control button, Hand accelerator operation lever and son on

Additional cooling system

The additional cooling system uses a mandatory water cooling for PTO. Can effectively control the fire truck equipment to extend the service life of equipment because of long hours of continuous work related to the heating

Additional Electrical system system

warning light ,warning sirens

Pump pneumatic control valve switch,Pump speedometer,Electronic level gauge

Fire lights, pump room lights, equipment box lights

Additional instrumentation

pressure gauge

speedometer

level gauge

vacuum gauge

Carriage

Carriage is made of high quality steel and Aluminum embossed sheet

Rolling shutter door

Light and high quality aluminum alloy rolling shutter door, neatly open and close, good seal, low noise, beauty outside, and with one set lock.

color

The whole vehicle is red for fire fighting, there are white in the middle of truck in accordance with the whole truck.
