ISUZU ELF 190hp 4x4 AWD 18 Meters Aerial Work Platform Truck

Folding arm lifting man truck was widely used in electric power, street lamps, municipal, garden, communications, airports, building (repair) ships, transportation, advertising, photography and other aerial work areas.




  • Brand:

    heritagetrucksolution.COM
  • Model No.:

    CL5110JGKIS18
  • Minimum Order Quantity:

    1 Unit
  • Price:

    USD 42100
  • Payment Terms:

    T/T, L/C, Western Union
  • Delivery Time:

    25~35 days after we get the deposit
  • Shipping:

    Ro-Ro/Bulk cargo/Container shipment / SKD / CKD / etc
  • Overview
  • Parameters

ISUZU 700P ELF 4x4 AWD 18 Meters Aerial Work Platform Truck

An aerial work platform is a mechanical device used to provide temporary access for people or equipment to inaccessible areas, usually at height to be used for temporary, flexible access purposes such as maintenance and construction work or by firefighters for emergency access.ISUZU 18 Meters Aerial Work Platform Truck is a folding type Aerial Platform Truck. It has three folding arms and provides temporary access for people or equipment to inaccessible areas of 18 meters height.


Quick Details



Chassis Brand

ISUZU

Horsepower

190hp

LHD/RHD

LHD

Type

Folding Type

Working Height

18 meters

Color

As requirements

Applications


Bucket Truck is mainly used for municipal engineering,municipal works, streetlight repair and maintenance, garden works, hotel decoration, building engineering work, electric power works, factory, large exhibition hall etc. And it is high efficiency and great performance with good safety.




Competitive Advantages


1.It uses ISUZU 4X4 type chassis, which has good performance in passing complex road surface and has a wider range of applications..


2.It is folding type, which has price advantage compared with telescopic type Bucket Truck. The working altitude can reach to 18 meters . And the bucket loading capacity is about 200KG with non-slip body.


3.Front H and rear H legs, good stability, which can be operated at the same time or independently, and adapt to a variety of working conditions.


4.Computer controlled, automatic limit, alarming when in dangerous work, excellent safety performance.


5.Slewing mechanism adopts adjustable type, which is easy to adjust.



Product Details


As professional aerial working truck factory,we provide different kinds of aerial truck to meet different customers requirements.
1. Aerial working height : 11m - 24m.
2. Different emission standard : Euro 1,Euro 2,Euro 3,Euro 4,Euro 5
3. Drive form has 4X2,4X4.
4. Chassis option FOTON, Dongfeng, JMC,JAC, FORLAND, etc.
5. Cabin option double-row ( 6 passengers ) and single row(3 passengers).
6. Steering wheel has left hand drive and right hand drive.
7. Aerial bucket can choose insulated bucket.

Customer Services


Pre sale service

--- Technical communication with engineer
--- Factory and workshop visit
--- Making design drawings


After Sale Service
--- Overseas installation & commissioning
--- Overseas and spare parts support
--- Technical and spare parts support

Truck

According to your request, choose good chassis and refit it to truck.


Upper Body
Supply only upper body without chassis. According to your chassis drawing,

design function parts.


Customization
Communicate with engineer,making design drawings and produce customized products.


Spare Parts
Supply all kinds of spare parts on chassis and upper body,replace main parts

on trucks as tank and box.




Product Parameters



Chassis Specification

Truck model

CLW5118JGKIS18

Cab

ISUZU 700P single row of seats cab, with air-conditional andUSB connector radio.

Driving Type

4*2 Left hand driving

Max Speed (km/h)

95

Overall dimension (mm)

Appro. 7400*1980*3200

GVW (kg)

Appro. 11000

Mass in working order( kg)

Appro. 8485

Wheelbase (mm)

3815

Tire

8.25R16

Clutch

Single-plate dry diaphragm spring clutch

Steering

Hydraulic steering with power assistance

Gear box

MLD 6-speed

Bridge

Front axle

4.0T

Rear axle

7.0T

Engine

Model

4HK1-TCG40

Fuel Type

Diesel fuel

Emission Standard

Europe V

Type

Water-cooled four-stroke, supercharged inter-cooling

Exhaust (ml)

2999

Max output power/rotate speed (hp /rpm )

190/3400

Max torque/rotate speed (N.m/rpm)

220/1700

BrakingSystem

Service Brake

Air brake

Park Brake

Spring energy

Electric system

24v

Special Function

Working height (m)

18

Max working radius (m)

9

Boom type

Two sections folding working boom

Rated loading in the bucket(kg)

200

Bucket size (mm)

1300*1000*1000

Rotating speed (r/min)

0-2

Rotationangle

360°

Supporting leg

four sets hydraulic legs

 Span of supporting legs

Horizontal

3500mm

longitudinal

4000mm

Boomcontrol mode

1.Bucket control

2.Manual operation

Supporting legs

Four hydraulic supporting legs with manual operation
