Brand:
heritagetrucksolution.COMModel No.:
CLW5350THB50X-6RZMinimum Order Quantity:
1 UnitPrice:
USD 318,500 FOB ShanghaiPayment Terms:
T/T, L/C, Western UnionDelivery Time:
25~35 days after we get the depositShipping:
Ro-Ro/Bulk cargo/Container shipment / SKD / CKD / etc
FAW heavy-duty 52m concrete
pump truck / 6x4 FAW 52m truck-mounted concrete pump
Our multifunctional concrete boom pump truck is designed by the well-known pumping research institute. With the domestic first-line counterparts using the same international brand parts, part of the configuration standards is higher than counterparts. After years of technological innovation, the structure has been further optimized, with better stability, lower failure rate and flexible operation.
Quick Details
12/7Mpa
Chassis brand
FAW
Dimension of vehicle
12230x2550x4000mm
Gross weight of vehicle
35000kg
Placeing boom at Max. height
52
Ratating angle of each arm
90°/180°/235°/180/180°
Max. Theoretical
throughput (high/low pressure)
50/80Mpa
Max. Concrete outlet pressure
Conveying cylinder inner diameter/stroke
Φ230x1650mm
Feeding height
1450mm
Concrete distribution valve form
S tube
Applications
The concrete pump truck is a modern construction machinery that integrates the transportation of finished concrete and the pouring process, to continuously, uniformly and promptly convey the premixed concrete to the form-work.
The application of pump trucks and the superiority of the pumping process make the pump trucks widely used in the construction of large concrete structures such as:
1) high-rise and super-high-rise buildings;
2) underground and tunnel projects;
3) port docks and dam projects;
4) roads and bridges and culvert projects.
Competitive Advantage
A. The continuous working pumping system blocks the segregation of concrete, hence the slump of the concrete will not be amplified, which visibly guarantees the quality of the construction operation.
B. The concrete pump truck concurrently solves the horizontal and vertical transportation also, pouring problems of concrete with high mechanization required few labor. The construction organization is simple yet suitable for structural materials thanks to high compressive strength it occupies.
C. The concrete pump truck casting operation requires continuous operation, with high construction efficiency and fast operation progress. Additionally, the similarity of expansion coefficient of concrete and steel bar resulted in intensive bonding strength contributing to reinforced concrete with a wider application range.
D. The concrete pump truck posses strong adaptability to the construction work surface with wide range of operations, the pipeline can be laid to places that are difficult to reach by other equipment. The concrete pump truck can fill and cast the concrete in place under a certain pressure, and also can be used in series to increase the output distance required during construction.
Product Details
Customer Services
Pre sale service
--- Technical communication with engineer
--- Factory and workshop visit
--- Making design drawings
After Sale Service
--- Overseas installation & commissioning
--- Overseas and spare parts support
--- Technical and spare parts support
Truck
According to your request, choose good chassis and refit it to truck.
Upper Body
design function parts.
Customization
Spare Parts
on trucks as tank and box.
Supply only upper body without chassis. According to your chassis drawing,
Communicate with engineer,making design drawings and produce customized products.
Supply all kinds of spare parts on chassis and upper body,replace main parts
Product Parameters
Preview |
Type |
Concrete Pump Truck |
|||||
Origin |
China |
||||||
Model |
CLW5350THB50X-6RZ |
||||||
Drive |
6×4 |
||||||
Height |
52 |
||||||
Vehicle dimension |
12230×2550×4000mm |
||||||
Gross vehicle weight |
35,000kg |
||||||
PARAMETER |
|||||||
A |
Vehicle |
||||||
1. |
Chassis |
Brand |
FAW |
- |
|||
Class |
Heavy-duty |
- |
|||||
Ex-factory |
2020 |
- |
|||||
Wheel |
Left-hand |
- |
|||||
Steer |
Power-assisted |
- |
|||||
Tyre |
12.00R20 (10 Qty) |
- |
|||||
Leaf spring |
11/12 |
- |
|||||
Brake |
Air brake with ABS |
- |
|||||
Cabin |
2 Seats with 1 single berth |
- |
|||||
Accumulator |
24 |
V |
|||||
Wheelbase |
4700+1350 |
mm |
|||||
Speed |
90 |
km/h |
|||||
2. |
Engine |
Model |
CA6DM2-39E51 |
- |
|||
Manufacturer |
Xichai |
- |
|||||
Fuel |
Diesel |
- |
|||||
Type |
Common rail(electronic control) |
- |
|||||
Intake |
Turbocharged |
- |
|||||
Cylinder (Arrangement) |
6 (In-line) |
- |
|||||
Displacement (Standard) |
11050 (Euro V) |
ml |
|||||
Theoretical output |
390/287 |
hp/kw |
|||||
Developed torque |
1750 |
N·m |
|||||
Rated speed |
1900 |
rpm |
|||||
Bore×Stroke |
123×155 |
mm |
|||||
Consumption at full load |
193 |
g/kw·h |
|||||
3. |
Angle
|
Approach |
23 |
° |
|||
Departure |
21 |
|
|||||
4. |
Suspension |
Front |
1470 |
mm |
|||
Rear |
1650 |
|
|||||
5. |
Wheel track |
Front |
2020 |
mm |
|||
Rear |
1878/1878 |
|
|||||
6. |
Axle load |
Front |
8000 |
kg |
|||
Rear |
13000/13000 |
|
|||||
Quantity |
3 |
- |
|||||
B |
Bodywork |
||||||
7. |
Placing boom |
Structure |
50-6RZ |
- |
|||
Max. Height |
50 |
m |
|||||
Max. Depth |
39 |
m |
|||||
Max. Radius |
46 |
m |
|||||
Slewing angle |
±270 |
° |
|||||
Feeding height |
1300 |
mm |
|||||
End hose length |
3 |
m |
|||||
Max. Aggregate size |
400 |
mm |
|||||
Concrete cylinder inner diameter×stroke |
Φ260X1800 |
mm |
|||||
Cleaning methodology |
Air or plunger pump |
- |
|||||
8. |
Pumping system |
Theoretical value limit to pressure |
High |
Low |
- |
||
A.Pumping displacement |
80 |
137 |
m3/h |
||||
B.Pumping frequency |
14 |
23 |
min-1 |
||||
C.Pumping pressure |
9.3 |
5.5 |
mpa |
||||
9. |
Hydraulic drive |
Hydraulic oil cooling |
Air-cooled |
- |
|||
Lubrication methodology |
Manual & Hydraulic |
|
|||||
10. |
Controlling |
High/low pressure switch-over |
Automatic & electronic |
- |
|||
Displacement control |
Electric displacement |
|
